Advantages and maintenance points of belt conveyor, composition and structure of belt conveyor

Xingtang Huaicheng Machinery Equipment Co., Ltd.

v

Key attributes

Product name Conveyor Belt
Automatic Grade Semi-automatic
Key Machines Conveyor Belt
Place of Origin China
Application Manufacturing, mining, docks, warehousing
After-sales Service Provided 1 Year
Color Customized Color

Technical Parameters

Specifications and models Bandwidth(mm) Conveying speed(m/s)
D500 500 0.8
D600 600 1-1.6
D800 800 1
D1000 1000 1
D1200 1200 1
D1400 1400 1

Working principle

The basic working principle of the belt conveyor is to rotate the drive roller through the motor, so that the belt circulates along the conveying route. The material is placed on the belt and moves to the destination with the belt. The conveying capacity and speed of the belt conveyor can be controlled by adjusting the power of the motor and the material of the belt.

Main components

Belt: The core component of the conveyor, usually made of rubber, PVC or other wear-resistant materials. The material selection of the belt is determined according to the characteristics of the conveyed material and the working environment.

Drive device: It includes the motor and the drive roller, which is the power source of the belt conveyor. The motor transmits power to the drive roller through the reducer to make the belt move.

Roller: It is used to support and guide the belt to prevent the belt from running off during the conveying process. Rollers can be divided into load-bearing rollers, transition rollers and return rollers according to their position and function.

Tensioning device: It is used to adjust the tension of the belt to ensure the smooth operation of the belt during the conveying process.

Frame: It supports the entire set of conveyor equipment, usually made of steel or aluminum, and has a sturdy and durable structure.



Advantages:

Long conveying distance: Belt conveyors can achieve long-distance and large-capacity material transportation.

Smooth operation: The belt conveyor runs smoothly, with low noise and low material damage rate.

Strong adaptability: It is suitable for the transportation of various materials, including bulk materials, finished items, etc.

High degree of automation: It is easy to integrate with other equipment to achieve automatic control.



Application areas

Mining and metallurgy: used to transport raw materials such as ore, coal, and metal.

Building materials: used in cement plants, brick plants, etc. to transport cement, sand and gravel and other building materials.

Food processing: used to transport food such as grain, candy, and beverages, usually with food-grade belts.

Logistics warehousing: used in warehouses, distribution centers, etc. to transport packages and goods to improve logistics efficiency.

Agriculture: used to transport agricultural products such as grain and feed to improve agricultural production efficiency.

w (4)



Company Profile

The company is located in Xingtang Economic Development Zone, Shijiazhuang City, Hebei Province. The company has been committed to the research, design, development and manufacturing of various types of dust collectors, bale crushers, pellet machines, hammer crushers, jaw crushers, shredders, magnetic separators, vibrating screens, dryers, sand washers, conveyors and other mining and livestock equipment.
Technical Strength:
Huaicheng Machinery has an efficient team of experienced engineers and technical experts, constantly pursuing technological innovation and product upgrades.
Manufacturing Process:
Huaicheng Machinery has advanced production equipment and a strict quality control system to ensure that each equipment can meet customer requirements.
Customer Service:
Huaicheng Machinery always puts customer needs first and takes it as its responsibility to meet customer needs.

1236

our factory

Attend exhibitions

Customer   visit

Team photo
Pack and Ship

The machine is wrapped in film, which is effectively waterproof and dustproof. When the machines arrive at your facility, they will be clean and brand new.

Pack and ship



FAQ

1. Who are we?
We are headquartered in Hebei, China, starting in 2020, selling to South Asia (20.00%), East Asia (20.00%), Middle East (10.00%),Southeast Asia (10.00%), North America (10.00%). There are about 201-300 people in our office in total.
2. How do we ensure quality?
Before mass production is always a pre-production sample;
Always conduct final inspection before shipment;
3. What can you buy from us?
Dust collector, magnetic extractor, linear vibrating screen, sand washing machine, drum dryer.
4. Why should you buy from us instead of other suppliers?
The company adheres to the concept of “technology first, integrity first” and has won the trust of our customers with
technology and product quality, reasonable prices, and timely service.
5. What services can we provide?
Accept delivery terms: CFR、CIF、EXW、CIP、FCA、DDP;
Accepted payment currencies: US dollars, euros, Japanese, Canadian dollars, Hong Kong dollars, British pounds, RMB;
Accepted payment methods: T/T, L/C, Western Union;
Spoken Languages: English, Chinese, Japanese
